TB18E
Overall Width ：2.49m
Working Height：20m
Electric drive with zero-emission and low noise.
4WD (Four-Wheel Drive) system,equipped with full-time swing axles, outstanding off-road capability.
keyword：
Articulated Boom Lift
Measurements
| Measurement | Metric | |
| Maximum working height | 20.1 m | |
| Maximum platform height | 18.1 m | |
| Machine length | 9.6 m | |
| Machine width | 2.49 m | |
| Machine height | 2.64 m | |
| Platform length | 1.8 m | |
| Platform width | 0.76 m | |
| Minimum ground clearance - center | 0.3 m | |
| Wheelbase | 2.5 m | |
| Tire | 315/55 D20 |
Weight
| Weight | ||
| Machine weight | 8700 kg |
Productivity
| Performance | ||
| Workload | 300 kg | |
| Workload - Limited | 450 kg | |
| Driving speed - collection status | 4.8 km/h | |
| Travel speed - lifting state | 0.8 km/h | |
| Inner min turn radius | 2.5 m | |
| Outer min turn radius | 5 m | |
| Turntable tail swing | 1.6 m | |
| Maximum climbing ability | 45% | |
| Maximum number of workers | 2 | |
| Allowable working angle | 3°/4° | |
| Turntable rotation angle | 360° | |
| Platform swing angle | 160° |
Power
| Power | ||
| Power | 48V DC | |
| Battery capacity | 420 AH |
①The working height is equal to the platform height plus 2 meters.
②The weight refers to the standard configuration and may vary depending on options and national standards.
