TB26E
Overall Width ：2.49m
Working Height：28.6m
Electric drive with zero-emission and low noise.
4WD (Four-Wheel Drive) system,equipped with full-time swing axles, outstanding off-road capability.
keyword：
Articulated Boom Lift
Measurements
| Measurement | Metric | |
| Maximum working height | 28.3 m | |
| Maximum platform height | 26.3 m | |
| Machine length | 11.65 m | |
| Machine width | 2.49 m | |
| Machine height | 2.93 m | |
| Platform length | 2.2 m | |
| Platform width | 0.8 m | |
| Minimum ground clearance - center | 0.3 m | |
| Wheelbase | 3.2 m | |
| Tire | 385/45 - 28 |
Weight
| Weight | ||
| Machine weight | 16500 kg |
Productivity
| Performance | ||
| Workload | 300 kg | |
| Workload - Limited | 450 kg | |
| Driving speed - collection status | 4.8 km/h | |
| Travel speed - lifting state | 0.8 km/h | |
| Inner min turn radius | 3 m | |
| Outer min turn radius | 6.6 m | |
| Turntable tail swing | 1.98 m | |
| Maximum climbing ability | 45% | |
| Maximum number of workers | 2 | |
| Allowable working angle | 5° | |
| Turntable rotation angle | 360° | |
| Platform swing angle | 160° |
Power
| Power | ||
| Power | 80V (lithium battery) | |
| Battery capacity | 460 AH |
①The working height is equal to the platform height plus 2 meters.
②The weight refers to the standard configuration and may vary depending on options and national standards.
