TB22F

The TB22F diesel telescopic boom lift delivers powerful performance with a 45% gradeability, making it an exceptional diesel telescopic boom lift. This diesel telescopic boom lift supports a maximum load of 450 kg and is equipped with four-wheel drive and full-time oscillating axles, ensuring outstanding off-road capability for the diesel telescopic boom lift across various terrains. It is the ideal diesel telescopic boom lift choice for demanding applications.

Working Height：24.15m
Overall Width ：2.42m
Platform capacity：300kg

keyword：

Diesel Telescopic Boom Lift

Classification：

Diesel Telescopic Boom Lift

Tel：

+86 0731-84822566

E-mail：

TB22F

Measurements

Measurement		Metric
Measurement		Metric
Maximum working height		24.15 m
Maximum platform height		22.15 m
Machine length		10.65 m
Machine width		2.42 m
Machine height		2.71 m
Platform length		2.2 m
Platform width		0.8 m
Minimum ground clearance - center		0.4 m
Wheelbase		2.52 m
Tire		355/55D625

Weight

Weight
Machine weight		14890 kg

Productivity

Performance
Workload		300 kg
Workload - Limited		450 kg
Driving speed - collection status		4.8 km/h
Travel speed - lifting state		0.8 km/h
Inner min turn radius		2.16 m
Outer min turn radius		4.98 m
Turntable tail swing		1.32 m
Maximum climbing ability		45%
Maximum number of workers		2
Allowable working angle		5°
Turntable rotation angle		360°
Platform swing angle		160°

Power

Power
Power		Cummins QSF2.8 C49 37kW
Fuel capacity		150L

①The working height is equal to the platform height plus 2 meters.
②The weight refers to the standard configuration and may vary depending on options and national standards.
