AB16E

The AB16E electric articulated boom lift is a high-performance electric articulated boom lift powered by electricity, enabling low-noise and zero-emission environmentally friendly operation. This electric articulated boom lift is equipped with a powerful four-wheel drive system, ensuring that the electric articulated boom lift operates efficiently and safely across various job sites. It is the ideal electric articulated boom lift for demanding aerial tasks.

Working Height：18m
Overall Width ：2.32m
Platform capacity：230kg

keyword：

Electric Articulating Boom Lift

Classification：

Electric Articulating Boom Lift

Tel：

+86 0731-84822566

E-mail：

info@kingdamade.com

Related Products

Advisory Message

AB16E

Mobile Elevated Work Platforms are reshaping the way high-altitude operations are carried out across construction, maintenance, and industrial sectors worldwide. Designed for safety, stability, and flexibility, these platforms provide secure lifting solutions for workers performing tasks at height, from building installation to facility repair and warehouse management. Equipped with advanced hydraulic systems and intuitive controls, they ensure smooth elevation and precise positioning even in confined or uneven work environments. Modern models emphasize enhanced safety features such as overload protection, anti-slip platforms, and emergency descent systems, significantly reducing operational risks. Their compact design and strong maneuverability allow easy deployment both indoors and outdoors, improving productivity while minimizing labor intensity. As industries continue to prioritize efficiency and worker safety, mobile elevated work platforms are becoming an essential tool in modern engineering and infrastructure development.

AB14E

AB14EN

Measurements

Measurement	Metric	Imperial
Measurement	Metric	Imperial
Working height max.1	18 m	59ft1in
Platform height max.	16 m	52ft6in
Horizontal reach max. (restricted)	8.2m	26ftllin
Horizontal reach max.(unrestricted)	9m	29ft6in
Up and over clearance max.	7.65 m	25ftlin
Machine length(stowed)ect)	7.56 m	24ft10in
Machine width	2.32 m	7ft7in
Machine height	2.34 m	7ft8in
Platform length	1.8 m	5ft11in
Platform width	0.8m	2ft7in
Ground clearance -center	0.24 m	Oft9in
Wheelbase	2.35 m	7ft9in
Tire	250 - 15

Weight

Weight	Metric	Imperial
Machine weight²	8490 kg	18717 lb4oz

Performance

Performance	Metric	Imperial
Rated load	230 kg	507 lbloz
Rated load- restricted	350 kg	771 lb10oz
Drive speed-lowered travel position	4.8 km/h	2.98 mph
Drive speed -elevated travel position	0.8 km/h	0.50 mph
Turning radius (inside)	1.9 m	6ft3in
Turning radius (outside)	4.7 m	15ft5in
Turntable tailswing	0 m	oftoin
Gradeability- stowed position	30%
Max. platform occupancy	2
Allowable tilt angle (front to back/sideto side)	5°
Turntable slewing	355°
Platform rotation	160°

Power

Power
Power (AGM battery/lithium battery)		48V DC/48V DC
Battery capacity		351 AH/400 AH

①The working height is equal to the platform height plus 2 meters.
②The weight refers to the standard configuration and may vary depending on options and national standards.
